Description
PRODUCT OVERVIEWS:
- Centralize your file storage, sharing and backup with excellent performance
- Run multiple Windows®, Linux®, UNIX® and Android™ based virtual machines with the Virtualization Station
- Operate multiple isolated Linux® systems as well as download containerized apps with Container Station
- Enjoy the best audio-visual experience with HDMI output and the free remote control
- Transcode Full HD videos on-the-fly or offline*
- Stream multimedia files via DLNA®, AirPlay®, Chromecast™ and Bluetooth® with multi-zone multimedia control
- Quickly find specific files by real-time, natural search with Qsirch
- Scale up to 12 drives with QNAP UX-800P expansion enclosure
Quad-core 64-bit Intel® Celeron® CPU for exceptional performance
The TS-451+ is powered by a 64-bit Intel® Celeron® quad-core 2.0GHz processor and has 2GB/8GB energy-efficient DDR3L RAM (upgradable to 8GB) and dual Gigabit LAN ports, delivering up to 225 MB/s read & write speeds with port trunking mode. The TS-451+ can also automatically increase the processor's clock rate from 2.0GHz to 2.42GHz when needed for CPU-intensive tasks. The TS-451+ supports AES 256-bit volume & folder encryption with transfer speeds of up to 204 MB/s, boosting system performance & security while ensuring the safety of sensitive personal data stored in the TS-451+.
 |  |
Tested in QNAP Lab. Figures could vary by environment.
Test environment:
NAS:
OS: QTS 4.2.0
Volume type: RAID 5; 4 x Seagate 1TB HDD (ST1000NM0033)
Network environment: direct connection between NAS and PC, 1GbE LAN (MTU 1500)
Client PCs:
Intel® Core™ i7-4790 3.60GHz CPU; DDR3-1600 16GB; Seagate 500GB ST500DM002; Intel Gigabit CT (MTU 1500);Windows® 7Professional 64bit SP1
IOMeter configuration: Transferring 8GB file continuously to/from 4 PCs for 3 minutes. Block size: 64KB for SMB2.0 (Throughput)
QTS 4.2 - Simple and efficient
Thanks to the intuitive user interface of QTS 4.2, your NAS experience is smarter, smoother and spectacular. Its modern flat design streamlines loading times, and the intelligent desktop allows you to quickly find desired functions, create desktop shortcuts or group shortcuts, monitor important system information on a real-time basis, and open multiple application windows to run multiple tasks concurrently, bringing greater operating efficiency. QTS breaks the barriers of devices, platforms and geography to bring optimized cloud experiences to you, and incorporates more advanced features including volume/LUN snapshot, remote connection to public cloud services in File Station, multi-zone multimedia system, and more.
Learn more: QTS 4.2
Container Station – LXC and Docker® Containers inclusive
QNAP Container Station exclusively integrates LXC and Docker® lightweight virtualization technologies, allowing you to operate multiple isolated Linux® systems on the TS-451+ as well as download apps from the built-in Docker Hub® Registry. It supports container import/export and permission settings, and features an informative dashboard and flexible user interface for you to manage multiple containers. You can experience the amazing Container Station and enjoy the playground of virtual containers with the TS-451+. Container Station also supports Online Document app, which allows you to directly view, edit and store files of various types anytime on your NAS, including Office documents, images and text files.
Qsirch – A smarter, faster way to search
Quickly and easily find documents, photos, videos, and music with Qsirch, QNAP's new built-in NAS search application lets you find what you need by real-time, natural search. Simply type in as much as you know about what you are trying to find, including parts of the file name or even words/phrases in the document, and Qsirch will display a list of matches, complete with thumbnails, as you type. Qsirch even remembers your search history so you can quickly navigate to files you've previously searched for. Qsirch is a huge productivity boost that greatly reduces the amount of time spent looking for files on the NAS so you can focus on other tasks.
Learn more: Qsirch
Cross-platform file sharing, centralized data storage
The TS-451+ supports SMB/CIFS, NFS, and AFP protocols for file sharing across Windows®, Mac® and Linux®/UNIX®. Data, logs and ISO image of CDs and DVDs can be centrally stored in the TS-451+ and protected by an integrated antivirus solution.
File Station integrated with cloud services
The web-based File Station enables you to easily upload, download, and manage files on your TS-451+ wherever there is an internet connection. Supporting file extraction, folder creation, and smart search for files and folders, the File Station also allows you to easily share files with colleagues and friends via unique URLs, email, and a shared space. What's even better, you can also directly browse and transfer files between the TS-451+ and public cloud services like Google Drive™, Dropbox®, Microsoft® OneDrive, Box®, Yandex® Disk and Amazon® Cloud Drive through File Station, and view files with Office Online and Google Docs™ or directly open them with a Google Chrome™ office extension.
Well-rounded backup solutions to secure data
QNAP NetBak Replicator supports real-time and scheduled data backup on Windows including Outlook email archiving. Apple Time Machine® is also supported to provide Mac® OS X users with a solution to effortlessly back up data to the TS-451+. The front panel USB 3.0 port on the TS-451+ features a one-touch-copy function for you to instantly back up data on external drives to the TS-451+ with just one click, or alternatively to back up data from the TS-451+ to external drives. A wide range of third-party backup software such as Acronis® True Image and Symantec® Backup Exec are also supported.
Disaster recovery solutions bring peace of mind
The TS-451+ offers various data recovery options. RTRR (Real-Time Remote Replication) supports real time and scheduled data backup to remote QNAP NAS or FTP servers and synchronizes files to remote folders from local folders with better backup efficiency. You can enjoy backup versioning to preserve a certain amount of versions, with options of simple versioning to schedule how many versions should be retained and for how long, or smart versioning with a rotation scheme that automatically replaces earlier backup versions. The TS-451+ also supports rsync protocol to back up data to remote servers on a scheduled basis. Data can also be backed up to and restored from a range of cloud storage services, including Amazon® S3, Amazon® Glacier, Microsoft® Azure™, ElephantDrive®, Dropbox®, Google Drive™, Google Cloud Storage™, and more.
Volume & LUN snapshot simplifies restoration
Not limited to high-end models, the TS-451+ brings the highly-anticipated snapshot function for your flexible usage.QTS Storage Manager adds an easy-to-use web-based snapshot tool for you to easily back up and restore data on the TS-451+ back to any point of time to prevent loss of important data. You can take up to 256 snapshots per volume or LUN, efficiently replicate volume/LUN snapshots to remote servers by copying only the changes made, and quickly clone a volume /LUN snapshot as a local volume without interrupting the current system operation. You can even set up the system to automatically take a snapshot of the volume before backup via RTRR/rsync, even when the file is opened.
Note: Snapshot function requires a minimum 4GB RAM.
Comprehensive security options
In open network environments, data on the connected devices may be exposed in a potential hack. The TS-451+ provides numerous security options, such as 2-step verification, encrypted access, IP blocking, and more. Administrators can also control the access rights of each user to different folders, preventing unauthorized access to important files. The TS-451+ is validated with military-level FIPS 140-2 AES 256-bit encryption, preventing sensitive data from unauthorized access and breach even if the hard drives or the entire system were stolen.
Secure access with VPN Server & VPN Client
The TS-451+ can be a VPN server with L2TP/IPsec, OpenVPN, and PPTP support, allowing you to securely access data shared within the private local network. The TS-451+ also supports VPN Client for PPTP and OpenVPN to protect your privacy during data transmission.
File synchronization across devices and clouds
Qsync utility turns your TS-451+ into a safe, large-capacity data center for file synchronization. Any file uploaded to the TS-451+ will be made available for all linked devices, such as computers, laptops or mobile devices. Qsync is especially useful for frequent travelers to manage files and always have the most up-to-date files on different devices. Qsync provides multiple ways of file synchronization and group file sharing, greatly enhancing the flexibility of team projects and collaboration. It also supports centralized configuration, and allows you to remotely erase the Qsync folder on a lost device to avoid data breaches, and even restore it after you have retrieved the device. You can also install the Cloud Drive Sync app from QTS App Center to easily sync files with Google Drive™ and Dropbox® cloud storage.
Comprehensive surveillance solution providing 24/7 security
The TS-451+'s Surveillance Station offers a professional surveillance solution with a user-friendly management interface, a wide range of over 3,000 compatible IP camera models, and expandable IP camera channel licenses. It supports real-time monitoring, video & audio recording and playback with a wide range of customizable settings. You can also install the Vmobile app on your iOS® or Android™ devices to manage the monitoring of cameras anytime, anywhere, to safeguard your office environment, or install the Vcam mobile app to turn your device into a network camera to instantly record to your TS-451+. The TS-451+ offers 2 free IP camera channels and you can expand up to 40 channels by purchasing additional licenses.
Access and enjoy with your mobile devices
The TS-451+ is your private cloud storage that virtually enlarges the capacity of your smart mobile devices. Qfile allows you to access, upload, download, manage, and share stored files easily as if you are carrying tons of files in your pocket. If Qfile is installed on an iOS® device, users can also browse videos & photos stored on the TS-451+ and play on a TV via Apple® TV. Qmanager lets you monitor & manage the TS-451+ remotely and efficiently without turning on your PC. You can take and share digital notes with Qnotes, and enjoy and share music, photos and videos on the TS-451+ anywhere and anytime with Qmusic, Qphoto and Qvideo apps.
Install-on-demand apps to extend NAS functionality
The TS-451+ has a built-in App Center that provides various install-on-demand apps developed by QNAP and third-party developers, including tools for backup/sync, business, content management, communications, download, entertainment, and much more. It is also a centralized location for managing & updating installed apps. In addition, QNAP's development platform embraces the open-source spirit to enable developers to create their own apps, adding potentially limitless potential for the TS-451+.
LED indicators with adjustable brightness controls
With adjustable 3-stage brightness controls for LED indicators, the TS-451+ provides flexible LED brightness options. Based on the surrounding environment, you can adjust the brightness of all system indicators and also schedule the system to automatically dim the LEDs at certain times when needed.
Expand storage capacity easily
The TS-451+ supports online capacity expansion for archiving rapidly growing data by connecting a QNAP expansion enclosure. With the QNAP scale-up solution, the raw storage capacity can be expanded on demand*, making the TS-451+ an ideal file center with large storage capacity for storage-intensive business applications.
With the support of QJBOD Express (JBOD enclosures roaming)**, you can just connect a large capacity QNAP expansion enclosure to the TS-451+, and migrate data to another NAS through the JBOD enclosure without network connectivity.
The maximum raw storage capacity available by connecting a QNAP expansion enclosure:
| NAS Model | RAID Expansion Enclosure | No. of RAID Expansion Enclosure | Total HDD No. (NAS + Enclosure) | Max. Raw Capacity (TB)*** |
|---|---|---|---|---|
| TS-451+ | UX-800P | 1 | 12 | 96 |
| UX-500P | 1 | 9 | 72 |
*To expand the storage space with an UX expansion enclosure, please create a separate static volume or storage pool on the UX expansion unit.
**RAID groups of storage pools cannot cross multiple enclosures.
***The maximum capacity is calculated by using 8TB HDDs.
Learn more: QNAP expansion enclosures
Energy-saving & eco-friendly
The TS-451+ utilizes a 22nm CPU and DDR3L RAM which feature low voltage, low power consumption, maintaining high performance in system operations with the benefit of energy-saving. Other eco-friendly designs include S3 sleep mode, HDD standby, scheduled power on/off, hard disk standby mode, and Wake on LAN. QNAP also packs the TS-451+ in an eco-friendly box to minimize the environmental impact.
Learn more: S3 sleep mode, Scheduled power on/off or reset, Hard disk standby, Wake on LAN
Easy-to-use NAS management tools
The TS-451+ provides comprehensive system tools to increase management efficiency.
| With the SMTP and SMS settings on the Turbo NAS, system administrators will get notifications via SMS or email if an error occurs. |
| The Turbo NAS supports HDD S.M.A.R.T. (Self-Monitoring Analysis and Reporting Technology) which monitors the hard drive status, and sends out email notifications for administrators to take action. The HHD Health Scanning technology can also examine hard drive status and prevent possible data loss. |
|
Additional features
The TS-451+ supports various applications for home offices as an all-in-one Turbo NAS with cost-efficiency.
| The Turbo NAS supports FTP server to share large size files, coming with user-defined settings including bandwidth limitation, number of connections, and write-only permission. |
MANUFACTURER PARTS NUMBER : TS-451+-8G-US
PRODUCT SPECIFICATION:
</tr| CPU | Quad-core Intel® Celeron® 2.0GHz (burst up to 2.42GHz) |
|---|---|
| Floating Point Unit | V |
| GPU | Intel® HD Graphics |
| Hardware-Acclerated Transcoding | V |
| Memory | System memory: TS-451+-2G: 2GB DDR3L RAM (1 x 2GB) Total memory slots: 2 SODIMMTS-451+-8G: 8GB DDR3L RAM (2 x 4GB) Expandable up to: 8 GB NOTE: 1. When installing two memory modules, please ensure that they are the same size and ideally use the same type of RAM for both memory slots. 2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide |
| Flash Memory | 512MB |
| Drive | 4 x 2.5" or 3.5" SATA 6Gb/s, 3Gb/s HDD or SSD; hot swappable trays NOTE: For the HDD compatibility list, please visit https://www.qnap.com/compatibility |
| Expansion Unit | Max. 1 (UX-800P, UX-500P) |
| Gigabit LAN Ports | 2 |
| USB | 2 x USB 3.0 (Front: 1, Rear: 1) 2 x USB 2.0 (Rear) |
| IR Receiver | Yes (QNAP RM-IR002 remote control) |
| HDMI | 1 |
| LED Indicators | Power/Status, LAN, USB, HDD1-4 |
| Buttons | Power, Reset, USB Auto Copy |
| Alarm Buzzer | System warning&l |
