Aruba JL805A#ABA Instant On 1960 12-Port 10Gb Aggregator Smart Switch - 12x10GBase-T | 4X SFP+

Ports:

12 x 10Gb Ethernet (RJ45), 4 x 10Gb SFP+ (Uplink)

Layer Services Supported:

Layer 2 Support

Supported Protocols:

Auto-MDIX/MDI, Auto-VoIP, IGMP Snooping, IPv4, IPv6, Link Aggregation, Port Mirroring, RADIUS, SNMPv1, SNMPv2c, SNMPv3

MAC Address Table Size:

16K

Security Features:

DoS Attack Prevention, RADIUS Authentication

Static Routes:

512

Supported IEEE Standards:

802.1p, 802.1q, 802.1q/p, 802.3ab, 802.3an, 802.3u, 802.3x

Latency:

1.1 to 7.4 µs

Forwarding Rate:

238 Mpps

Switching Bandwidth:

320 Gb/s

CPU:

2 GHz Cortex A9 Single-Core

Power Draw:

160.00 W (Max), 80.00 W (Idle)

Current:

0.4 to 1.3 A

AC Input Power:

100 to 240 VAC, 50 / 60 Hz

Power Supply Type:

Internal

Cooling System:

Passive
